Torqeedo Ultralight 403

Our extremely light Ultralight 403 fits on all popular types of kayak, and there are special models for special requirements.

Varen kan ikke bestilles gjennom nettbutikken, vennligst kontakt oss på firmapost@westsystem.no for å gjøre et kjøp.

18.850,-

inkl. mva Kontakt oss Varenummer: TQ1404-00

Our extremely light Ultralight 403 fits on all popular types of kayak, and there are special models for special requirements.

Motor, battery and remote throttle cable are completely waterproof to IP 67. Regardless of whether your are kayaking on inland water or the sea, on protected or unprotected waters – the Ultralight 403 is your ideal companion for every adventure

Also for canoes and very small boats.

Ultralight 403 – Benefits:

  • Weight including battery: 8.9 kg
  • Maximum speed up to 10 km/h (boat-dependent), faster that any trolling motor
  • Range of up to 40 km at low speed (also boat-dependent)
  • Completely waterproof (IP 67)
  • Precise GPS-based calculation of remaining range
  • Solar rechargeable – including during the voyage

Ultralight 403 with Integrated Battery (29.6 V / 11 Ah)





Speed in km/h* Range in km* Running time in hours
Slow 4.2 35.2 08:20
Half throttle 6.0 25.0 04:10
Full throttle 9.3 7.4 00:48

* Depends on type of boat, load, propeller and conditions. Speed and range indications do not represent a legal guarantee.

Information on range and speed

For a displacement boat making way through the water, the required propulsive power increases in proportion to the cube of the speed. This means that if you want to double your speed, you need eight times as much power.

And vice-versa, a small reduction in speed is enough to increase the achievable range substantially.

The Torqeedo Ultralight's on-board computer calculates the remaining range constantly, by linking the motor's consumption data with the charging level of the batteries, and the speed over the ground from the GPS. This allows you to read the remaining range in real time from the motor display or the smartphone app TorqTrac.



Link for tekniske tegninger:

Torqeedo Ultralight 403

Batteri Ultralight 320Wh

Dimensjoner
Vekt 8,9 kg
Vekt uten batteri 4,4 kg
Vekt batteri 4,5 kg
Lengde på motorstamme 45 cm
Generelt
Batteritype 320 Wh Li-Ion
Ladetid (tomt) ca. 9 timer
Medfølgende batterilader Ja
Integrert kjørecomputer Ja
Dødmannsknapp Ja
Ytelse
Antall watt 400
Tilsvarer bensinmotor 1HP
Maks kjøretid ca 8 timer
